Alfanar J-YY Indoor Telephone Cable is designed for internal voice and communication wiring. It is used to interconnect telephone systems within buildings and provides excellent electrical performance and durability, making it ideal for residential and commercial environments.
✅ Key Features:
-
Suitable for permanent installations inside walls or conduits
-
Performs well in dry and damp indoor conditions
-
Economical and easy to install
-
Made with solid bare copper for long life and stable performance
-
Complies with IEC 60189-1 and IEC 60189-2 standards
✅ Construction & Components:
-
Conductor: Solid bare copper as per IEC 60228
-
Number of Pairs: 1 pair
-
Conductor Size: 0.5 mm
-
Max. DC Resistance at 20°C: 97.8 Ohm/km
-
Minimum Insulation Thickness: 0.15 mm
-
Minimum Sheath Thickness: 0.6 mm
-
Approx. Outer Diameter: 3 mm
-
Approx. Net Weight: 12 kg/km
-
Filler: Polyester
-
Insulation: PVC rated up to 70°C as per IEC 60189-2
-
Sheath: PVC rated up to 90°C as per IEC 60189-1
-
Rip Cord: Included for easy jacket removal
-
Pair Twisting: Each pair is twisted with different lay lengths to reduce crosstalk
-
Core Stranding: Pairs are stranded to form the cable core
✅ Packing:
-
Length: 100 yards (approx. 91.44 meters)
-
Other lengths available upon request
This cable is the ideal solution for indoor telephone installations, offering stable performance, minimal interference, and high-quality construction according to international standards.
