Alfanar Low Voltage Power Cable 3×95+3×50 mm² Copper XLPE/PVC Black – 1000m
Alfanar's 3×95+3×50 mm² copper power cable is designed for low-voltage applications requiring high-capacity main and auxiliary conductors. It features XLPE insulation and a durable black PVC sheath, rated at 0.6/1 kV and delivered in 1000-meter rolls for industrial-grade reliability.
* All Prices includes 15% Vat.
Fast Shipping
Carrier information
20k products
Payment methods
24/7 Support
Unlimited help desk
2-day Delivery
Track or off orders
| cores | 3 |
|---|---|
| length | 1000 meter |
Description
This Alfanar low voltage power cable features three main copper conductors with a cross-sectional area of 95 mm² and three auxiliary conductors of 50 mm², offering a dual-functionality design ideal for energy and control transmission in industrial settings. The XLPE insulation ensures high thermal and dielectric performance, while the black PVC sheath enhances protection and longevity. It operates at 0.6/1 kV and is supplied in 1000-meter lengths to accommodate large-scale installations.
Technical Specifications:
-
Conductor: Plain annealed copper
-
Core Configuration: 3×95 mm² + 3×50 mm²
-
Rated Voltage: 0.6/1 kV
-
Insulation: XLPE
-
Sheathing: Black PVC
-
Length: 1000 meters
-
Maximum Operating Temperature: 90°C
-
Product Code: C438XA10400MB08IMR
Applications:
Recommended for heavy-duty industrial environments, main distribution lines with integrated auxiliary control, substations, and manufacturing facilities requiring robust low-voltage cabling solutions.
