Alfanar low voltage power cable with 5 conductors × 25 mm² offers optimal current carrying capacity for a wide range of electrical distribution applications. Made from high-purity copper conductors, the cable is insulated with cross-linked polyethylene (XLPE) and covered with a robust black PVC sheath, offering superior protection against mechanical stress and environmental conditions. Designed to operate at 0.6/1 kV, this 1000-meter cable is suitable for fixed wiring in lighting systems, control panels, HVAC units, and power sockets.
Technical Specifications:
-
Conductor: Annealed copper, Class 2
-
Core Size: 5 cores × 25 mm²
-
Rated Voltage: 0.6/1 kV
-
Insulation: XLPE
-
Sheath: PVC – Black
-
Operating Temperature: Up to 90°C
-
Length: 1000 meters
-
Product Code: C316XA10500MB12IMR
Applications:
Designed for low voltage distribution in residential, commercial, and light industrial environments, especially for HVAC systems, distribution boards, and general fixed electrical wiring.
