Alfanar’s low voltage power cable includes three copper conductors, each with a 185 mm² cross-sectional area. It is insulated with XLPE and covered by a tough black PVC outer sheath. The cable is reinforced with a steel tape armoring (STA) for superior mechanical protection. Suitable for underground and industrial applications requiring high current capacity.
🔹 Technical Specifications:
-
Number of Cores: 3
-
Conductor Size: 185 mm²
-
Rated Voltage: 0.6/1 kV
-
Insulation: XLPE
-
Outer Sheath: PVC – Black
-
Conductor Material: Copper
-
Armor Type: Steel Tape Armored (STA)
-
Length: 500 meters
🔹 Applications:
-
Power distribution networks
-
Underground installations
-
High-capacity industrial areas
-
Power generation plants
📦 Product Code: C448XA10300GMB04IMF
