The Alfanar 3-core 240 mm² copper cable is engineered for robust and continuous low-voltage power transmission. It features XLPE insulation for thermal and dielectric performance, and a protective PVC outer sheath in black for environmental resistance. Designed for fixed installations and underground power networks, it complies with IEC 60502-1 standards, ensuring durability and safety.
🔧 Technical Specifications:
-
Rated Voltage: 0.6/1 kV
-
Number of Cores: 3 cores
-
Conductor Material: Copper
-
Insulation Material: XLPE
-
Sheath Material: PVC, Black
-
Cross-Sectional Area: 240 mm²
-
Cable Length: 500 meters
-
Operating Temperature: Up to 90°C
-
Standards Compliance: IEC 60502-1
🛠️ Applications:
-
Low voltage electrical distribution
-
Substations and fixed installations
-
Infrastructure and industrial facilities
📦 Item Code: C449XA10300MB04IMF
