Alfanar’s 3×70+3×35 mm² copper low voltage power cable is purpose-built for demanding environments, combining power and control transmission within one sheath. It contains three main 70 mm² conductors and three auxiliary 35 mm² conductors, ideal for systems requiring parallel signal routing. The XLPE insulation offers excellent thermal and electrical resistance, while the black PVC sheath provides additional durability and easy identification. Operating at a rated voltage of 0.6/1 kV, this cable is supplied in 1000-meter lengths for use in substations, heavy equipment, and industrial plants.
Technical Specifications:
-
Conductor: Copper
-
Configuration: 3×70 mm² + 3×35 mm²
-
Rated Voltage: 0.6/1 kV
-
Insulation Material: XLPE
-
Sheath Material: PVC – Black
-
Length: 1000 meters
-
Max Operating Temperature: 90°C
-
Product Code: C437XA10400MB08IMR
Applications:
Ideal for industrial installations, power distribution units, and control systems requiring both high power and auxiliary functionality in one cable.
